Single Side (IR) * |
Single Side (Vis) † |
Double Side (IR) * |
Double Side (Vis) † |
| Reflectivity |
<2.6% |
<2.9% |
<0.5% |
<1.0% |
| Transmittance |
>96% |
>94% |
>98% |
>98% |
| Ablation threshold |
Higher than pristine |
Higher than pristine |
Higher than pristine |
Higher than pristine |
Scratching
resistance‡ |
Low |
Low |
Low |
Low |
| Haze |
Tunable |
Tunable |
Tunable |
Tunable |
| Size |
Up to 24.5 x 24.5 cm |
Up to 24.5 x 24.5 cm |
Up to 24.5 x 24.5 cm |
Up to 24.5 x 24.5 cm |
| Thickness |
>700μm |
>700μm |
>700μm |
>700μm |
|
|
|
|
|
* Infrared: 700 – 1000nm
† Visible: 400 – 700nm
‡ Abrasion test: CS-8
Haze tunability: 0.2 – 12.5
